The first approach implies a maximum current, Imax, for the diode in the forward direction. The real diode we will use is a silicon 1N4004 400 V PIV, I max 1 A and the white line at one end indicates the direction in which positive forward current flows. Part I Diode Characteristics a Set up the following circuit with V, on the 4 VDC scale.

much current can the load draw without exceeding the diode specications? 3. Voltage Doubler Connect the voltage doubler circuit of Fig 2.3 using 1N4001 diodes and explain its action. in out 0.01 F 0.01 F Fig 2.3 Voltage Doubler 4. Diode Clipper The circuit of Fig 2.4 limits the range of a signal. Use the 1N914 signal diode when you build it.

What is the difference between a Zener diode and a quotstandardquot rectifier diode? 3. Draw a quotload linequot plot for a circuit with a d.c. source, forward biased diode and a resistor. The plot should have the diode voltage on the horizontal axis and current on the vertical axis. Mark both scales with numerical values in volts and mA, respectively.

Figure 1 Circuit for characterizing a diode's current-versus-voltage characteristics 2.The four circuits shown in Fig. 2 are diode-resistor and diode-capacitor combinations that perform clipping, recti cation, level shifting, and ltering. Construct each of these circuits using the diode board and variable resistor or capacitor boxes. Set R 1k

Diodes are common nonlinear circuit components. Here we will experimentally investigate the current-voltage I-V characteristics of diodes and the use of diodes in rectifier and limiter circuits. Objectives Obtain the I-V curves of a signal diode and a zener diode Compare the performance of different rectifier circuits . References

Finally, add a second opposing 1N4732 zener diode in series with the existing zener diode to produce the fourth limiter circuit D. Sketch a copy of the VTC in your lab notebook as well. Question-2 a Draw the VTC for the fourth limiter circuit if the zener diodes were connected in anti-parallel, rather than in anti-series as shown. Explain your

Due to this diode D1 is forward biased. It results a current Id1 through the load R. Circuit Diagram Full Wave Rectifier without filter Full Wave Rectifier with filter V NL DC voltage at the load without connecting the load Minimum current. V FL DC voltage at the load with load connected.

Electrical-engineering document from University of California, Riverside, 14 pages, 1 EE 005 Circuits and Electronics Department of Electrical and Computer Engineering University of California - Riverside Laboratory Manual LABORATORY 6 Diode Circuits CONTENTS Objectives . 2 Equipment. 2 Parts . 2 1. Theoretical Background . 4 1.1 Diodes

Sketch the input and output waveforms as well as the VTC of the circuit. Question-1 a Without performing any measurement, draw the VTC for the fourth limiter circuit D. b Without performing any measurement, draw the VTC for the fourth limiter circuit if the zener diodes were connected in anti-parallel, rather than in anti-series as shown.

This document describes an experiment to study the use of a Zener diode as a voltage regulator. The Zener diode exhibits a constant voltage when reverse biased beyond its breakdown voltage. This property allows it to regulate voltage supplied to a load. The experiment involves measuring the output voltage with and without a load present as the input voltage is varied. Results show the output
